Vibro-meter VM600 200-510-041-021 200-510-111-021-021MPC4 Digital Control Board
Vibro-meter VM600 200-510-041-021 200-510-111-021-021MPC4 Digital Control Board
Product Overview
Vibro-meter VM600 MPC4（Machine Protection Card 4） It is a digital control board used in the unit status monitoring and protection system.
Its main function is to:
Obtain vibration, position, velocity and other signals from front-end sensors and measurement modules;
Perform signal processing and logical operations;
Output digital control signals to the system for triggering alarms, interlocks, or trip actions.
This module belongs to the core safety and protection unit of the VM600 system, usually configured in pairs with redundancy (primary/backup) to ensure the safe operation of high-speed rotating equipment (such as steam turbines, gas turbines, compressors).
Technical Specifications
Model: MPC4
Part number:
200-510-041-021
200-510-111-021
Function: Digital logic processing and unit protection
Signal input: Digital signals from measurement modules (such as XMV16 vibration module, IOC4T interface module)
Logical function:
Comparison of numerical quantities
Threshold judgment
Interlocking condition logic combination
Output interface:
Output alarm/trip signal to IOC module
Connect with the unit DCS or ESD system
Redundancy feature: Supports 1oo2 and 2oo3 logical voting structures
Communication method: Interact with RCU (Rack Control Unit) and other modules through VM600 system bus
Working environment:
Temperature: 0~60 ℃
Humidity: 5%~95% (without condensation)
Installation method: VM600 19 “rack slot type
