ABB CSA463AE Network Module for Industrial Automation

ABB CSA463AE Industrial Ethernet Communication Module

The ABB CSA463AE delivers high-performance industrial networking with 100 Mbps Ethernet connectivity for real-time control systems. Engineered for harsh environments, this module ensures uninterrupted data exchange in critical applications from manufacturing plants to process control facilities.

Technical Specifications

• Manufacturer: ABB
• Model: CSA463AE
• Product Type: Industrial Ethernet Communication Module
• Operating Voltage: 24 V DC ±10%
• Data Rate: 100 Mbps (Full-duplex)
• Interface: RJ45 Ethernet with auto-negotiation
• Certifications: CE, UL, RoHS, IEC 61131-2 compliant
• Dimensions: 200 × 150 × 100 mm (W×H×D)
• Operating Temp: -25°C to +70°C

Performance Advantages

• Deterministic data transmission with <1ms latency for real-time control
• Dual-stack IPv4/IPv6 support for future-proof networking
• Integrated diagnostics LEDs for rapid troubleshooting
• EMC-tested for industrial environments (EN 61000-6-2/4)
• Vibration-resistant construction (up to 5g @ 10-150Hz)

Industrial Integration

Seamlessly interfaces with ABB AC 800M controllers and third-party systems via Modbus TCP. The DIN-rail mountable design simplifies installation in control cabinets while galvanic isolation protects against ground loops. Supports PROFINET, EtherNet/IP, and OPC UA protocols for multi-vendor interoperability.
