B&R 7AI77470 Industrial Analog Input Module: Precision Data Acquisition

Engineered for critical process control applications, the B&R 7AI77470 delivers laboratory-grade measurement accuracy in industrial environments. This 8-channel analog input module captures high-fidelity signals with 16-bit resolution across a ±10V range.

Technical Specifications

• Manufacturer: B&R Automation
• Model: 7AI77470
• Type: Analog Input Module
• Channels: 8 isolated inputs
• Signal Range: -10V to +10V
• Resolution: 16-bit (0.0003% accuracy)
• Sampling Rate: 100 kHz aggregate
• Communication: Profibus, Profinet, EtherCAT
• Power Supply: 24V DC (±10%)
• Operating Temp: -25°C to +60°C
• Dimensions: 110 × 100 × 50 mm

Performance Advantages

The 7AI77470 features signal conditioning circuitry that maintains ±0.01% linearity even in electrically noisy environments. Its industrial-grade components withstand vibration, temperature extremes, and humidity fluctuations common in manufacturing plants. The module’s galvanic isolation prevents ground loops while its diagnostic LEDs provide instant status monitoring.

With multi-protocol support, this module integrates seamlessly into existing control architectures. The 100kHz sampling capability enables real-time process monitoring for applications like precision machining, quality inspection systems, and test bench instrumentation.

Stoker Automation Support

This product includes our 24-month performance warranty. Our engineering team provides application-specific configuration guidance and troubleshooting. For specialized requirements or obsolete parts, contact our technical specialists.
