GE DS3800NEPA1D1C – Motor Exciter Power Board for Mark IV Turbo Management System
The DS3800NEPA1D1C is a high-performance motor exciter power board specifically designed for the Mark IV series by General Electric. It plays a pivotal role in steam or gas turbine management, ensuring safe and efficient operation.
- Manufacturer: General Electric
- Model Number: DS3800NEPA1D1C
- Board Type: Motor Exciter Power Board
- Compatibility: Mark IV (Speedtronic) Series
- Height: Significant due to two 44B379508-G02 modules from Raycom Electronics
- Module Configuration: Two 44B379508-G02 modules near the center of the board
- Connector Type: Male straight-pin connectors with 6-, 7-, and 8-pin configurations
- Terminal Connector: One multi-pin terminal connector in the upper left corner
- Resistors: Two 10W 71Ω 5% resistors (black), nine large banded metal film resistors
- Capacitors: Nine large capacitors included
- Jumper Switch Settings: One jumper switch with settings of ‘rev’ or ‘nr’
The DS3800NEPA1D1C is meticulously crafted by General Electric to enhance the efficiency and safety of turbine systems. This advanced power board is tailored for the Mark IV series, known for its robust design and reliability. Featuring a unique configuration that includes two high-quality 44B379508-G02 modules, this board ensures superior performance under various operational conditions. Its compact yet efficient design allows for seamless integration into existing systems, while its robust connectivity options make it a versatile choice for industrial applications. With its advanced features, including a jumper switch and integrated circuits, the DS3800NEPA1D1C offers unparalleled precision and control, making it an essential component for any modern turbine system. Its compatibility with the Mark IV series guarantees seamless operation and easy maintenance.
