GE SR469-P5-HI-A20-D-0 Motor Management Relay

GE SR469-P5-HI-A20-D-0 Motor Management Relay

    The GE SR469-P5-HI-A20-D-0 Motor Management Relay is a sophisticated device designed to protect and monitor motor systems. It integrates advanced technologies for thermal monitoring, current unbalance detection, and protective relays, making it an essential tool for industries relying on efficient and reliable motor operations.

Key Features:

• Voltage Supply: AC 70 to 265 V @ 48-62 Hz
• Phase Current: 5A
• Phase Protocol: Modbus RTU/Half Duplex
• Analog Outputs: 4-20 mA Burden > 500 kΩ
• Case Mounting: Panel or 19-inch rack mount
• Control Power: 90-300VDC and 70-265VAC at 48-62Hz
• RTD Inputs: Three-wire 100 ohm Nickel, 120 ohm Nickel, 10 ohm Copper, 100 ohm Platinum
• Torque Protection: Mechanical Jam, Undervoltage & Overvoltage Protection, Current Unbalance Correction
• Ethernet Connection: Optional 10BaseT, RJ45

    This relay is an indispensable component for any industrial control system aiming to optimize motor efficiency and longevity. Featuring a robust design, it can monitor multiple parameters including phase current, voltage, and temperature, enabling early detection of potential issues before they escalate into costly failures.

    The unit supports the Modbus RTU protocol over half-duplex connections, ensuring seamless integration into existing systems. Its four 4-20mA analog outputs allow users to monitor and control various aspects of motor performance, contributing to overall system reliability. Designed for harsh environments, this relay ensures continuous operation even under extreme conditions.

    With its modular design, the GE SR469-P5-HI-A20-D-0 facilitates easy installation and maintenance, reducing downtime and operational costs. For more information or assistance, feel free to contact us via email.
