SEW BTS20-300-40 IGBT Power Module
Stoker Automation Technology – Your Trusted Industrial Partner Since 2005. With 5,000m² warehouse and 20+ years expertise, we provide premium automation components for metallurgy, energy, manufacturing and 30+ industries. Enjoy 2-year warranty and 24/7 technical support.
Technical Specifications
- Module Type: IGBT Power Module
- Rated Voltage: 600V DC
- Continuous Current: 300A @ 80°C
- Switching Frequency: 20kHz (Max)
- Thermal Resistance: 0.15K/W
- Operating Temp: -40°C to +150°C
- Protection Class: IP20 (DIN EN 60529)
- Dimensions: 200×150×50mm
- Weight: 4.5kg ±5%
Key Features
✓ Precision-engineered for harsh industrial environments
✓ Integrated overcurrent/short-circuit protection
✓ Low VCE(sat) for reduced power losses
✓ 99.2% efficiency rating (typical)
✓ Forced air cooling compatible
✓ CE & UL certified
Application Scenarios
Ideal for:
• Motor drives in steel mills
• High-power frequency converters
• Renewable energy systems
• Mining equipment power control
• Railway traction systems
⚠️ Note: Custom configurations available. Can’t find your model? Email us at abbdcs36@gmail.com with your requirements.
